TFT LCD Display Module 2 Inch 320x240 RGB 6Bit Digital Home Appliance ODM

Brand Name : RGH

Model Number : RT20LQ055E

Place of Origin : Shenzhern,China

MOQ : 3PCS

Price : Negotiable

Certification : ISO9001/ISO14001

Payment Terms : L/C, T/T,Paypal

Supply Ability : 3.5kk

Delivery Time : 3-5weeks

Packaging Details : Standard Exportation Package

Screen Size : 2.0 inch

Resolution : 320(RGB)X240

Interface : RGB

Brightness : 480 cd/m²

Dimensions : 46.10(W)X40.96(H)X2.53(T)

Display Type : Thin Film Transistor Liquid Crystal Display

Viewing Angle : 12:00o'clock

Backlight Type : LED

Contact Now

TFT LCD Display Module 2 Inch 320x240 RGB 6Bit Digital Home Appliance ODM

NO.	Symbol	Level	Function
1-9	DUMMY
10	VGH		2.2uf25V
11	VGL		2.2uf25V
12	GND	VSS	Ground.
13-18	DUMMY
19	LED-		LED,cathode.
20-21	DUMMY		No connection.
22	LED+		LED,cathode.
23	GND	VSs	Ground.
24	VCC	2.8V(typ)	Power supply
25	VSYNC	H/L	Frame synchronizing signal for RGB.
26	HSYNC	H/L	Line synchronizing signal for RGB.
27	DCLK	H/L	Dot clock signal for RGB.
28-29	GND	VSs	Ground.
30-35	DB0-DB5	H/L	Data bus.
36	SDA	H/L	Serial inlout signal.
37	SCL	H/L	Serial interface clock.
38	CS	H/L	Chip selection.
39	NC		No connection.
40	RESET	H/L	Reset signal.

TFT LCD Display Module 2 Inch 320x240 RGB 6Bit Digital Home Appliance ODM

FAQ

1: What are the payment terms?
A: We usually accept T/T, Paypal, other terms to be negotiated.

2: What’s the lead time?
A: Usually 3~5 days for sample orders if goods are in stock, and 3~5 weeks for mass production (basing on the quantity and product).

3. Do you support custom logo on the LCM?

A: Yes, we support, pls send us your detail inquiry, our sales will contact you asap.

4. How can I place a sample order?

A: Pls send us your inquiry, our sales will contact you soon.

5. What size LCD display can you provide?

A: 0.96 inch to 21.5 inch TFT LCD display we can provide.

7. What's your MOQ?

A: Most of our product's MOQ is 1K, beacuse we are a LCD display manufacturer.

8. What shipping ways do you support?

A: We can consult with it.
